B100 size 125-180 μm Ceramic blasting for stainless steel,
aluminum, titanium, magnesium, etc
DESCRIPTION
The ceramic beads are spherical shaped blasting media with high
mechanical strength and high wear rates, also with good round
consistency and chemically stability.
Ceramic beads blasting Sizes range from B20 to B505, available in
coarse, fine and very fine sizes sandblasting.
Ceramic beads is applicable for sandblasting for various materials,
including steel, stainless steel, aluminum, titanium, magnesium,
brass, copper and plastics, etc.
Ceramic blast media is very versatile and can be blasted with all
delivery systems.
SPECIFICATION
Manufacturing process: Melting method
| ZrO2 | SiO2 | Al2O3 | Other |
| 60-66%, | 25-30% max. | 7-13% max. | 5-8% |
| Color | Bulk Density | True Specific Density | Vickers Hardness |
| White | 2.3g/cm3 | 3.85g/cm3 | 700 HV |
Sizes Available:
| B20:0.600-0.850mm | B120:0.063-0.125mm |
| B30:0.425-0.600mm | B150:0.053-0.106mm |
| B40:0.250-0.425mm | B170:0.045-0.090mm |
| B60:0.150-0.300mm | B205:0.000-0.063mm |
| B80:0.180-0.250mm | B400:0.030-0.063mm |
| B100: 0.106-0.180mm | B505:0.010-0.063mm |
Special specifications can be customized.
PRODUCTION PROCESS
FEATURES
- Strong chemical resistance
Guarantees constant performance eg. consistent Surface blasting
effect.
Does not contaminate the work piece surface, and no hidden danger
of silicosis, it is harmless to the human body.
Recyclable,and can reduce the refueling times, improve working
efficiency.
APPLICATION
1) 3C products - Sandblasting Finishing
Alloy shell, middle frame and built-in parts of computers, mobile
phones, cameras, etc. - sandblasting finishing
Clean burrs to form film-light decorative or fine reflective
surface, on alloy workpiece such as mobile phone to achieve
different reflection or matte.
2) Kitchen Industry-Sandblasting finishing
Stainless steel cutlery and kitchen utensils sandblasting finishing
3) Golf club - Sandblasting finishing
Golf club & ball head alloy surface treatment Sandblasting
finishing
4) Casting and forging parts, welded parts, heat-treated parts -
Sandblast Cleaning
Clean all the dirt on the surface of the alloy workpiece, micro
burrs, improve the flatness and smoothness of the workpiece, and
expose to uniform metallic color, achieving smooth and
non-reflective requirements on surface.
5) Pipeline - Sandblast Cleaning
Metal pipes such as copper pipes and steel pipes are cleaned and
polished on the inner and outer walls.
6) Molds - Sandblast cleaning
Cleaning of molds of glass bottles, tires, etc., rust, dirt and
impurities.
7) Electroplating, painting, anode-Surface Pretreatment
Electroplating, painting, anode, Teflon, rubber, plastic,
traversing, metal, spray welding, gold plating, titanium plating,
etc., to remove dirt and increase product surface adhesion.
8) Hardware parts - Sandblasting to improve lubrication conditions
It can produce uniform and fine uneven surface on the surface of
the part, so that the lubricating oil can be stored, improve the
lubrication condition and reduce the noise.
1) Aerospace industry-Shot Peening
Suitable for aerospace engine components, aircraft landing gear,
gear transmissions, aero-engine blades, aircraft wing-shot peening
2) Automotive industry-Sandblasting reinforcement/ Shot Peening
Suitable for gearbox gears, automotive aluminum hubs, piston
components/shock absorbers, engine crankshaft sandblasting
reinforcement/shot peening
3) Machinery, Medical Instrument - Sandblast finishing/shot peening
The overall sandblasting and polishing, finishing, restore the
natural color of the metal, enhance the visual effect and texture,
and also shot peening reinforcement to improve its worklife.
APPLICABLE EQUIPMENT
- Air Blasting cabinet
- Air blasting blast pots
- Air blasting rooms
- Automated blasting equipment
- Shot peening equipment
- Micro blasting quipment
- Wheep blast equipent
