4.0g/cm3 Zirconium Silicate Balls 65 Zirconia Beads Milling Media
1.4-1.6mm for Paint
1. Product Description of Zirconium Silicate Beads
Zirconium silicate beads is one grinding media with higher
price/performace ratio,it selected the high-purity
and ultra-fine zirconium silicate powder as main material,then made
into different beads by process of
sintering,polishing...
It is widely used for the materials with medium viscosity.
2. Main Technical Data of Zirconium Silicate Beads
| Item | 65 Zirconium Silicate Beads | 95 Zirconia Beads |
| Chemical Index | ZrO2 ≥65% SiO2 25-30% Others ≤1.0% | ZrO2 ≥95% Y2O3 ≥4.5% Others ≤0.5% |
|
|
| Color | Yellow-white, not bright and opaque | White with pearly luster |
| Hardness | 8 Mohs | 9 Mohs |
| True Specific Gravity | ≥4.0g/cm3 | ≥6.0 g/cm3 |
| Bulk Density | ≥2.5g/cm3 | ≥3.7g/cm3 |
| Particle Size | Φ0.1-10mm etc. | Φ0.1-50mm etc. |
| Different Applications | Grinding media,widely used for grinding&dispersing of low or
medium viscosity slurry | Grinding of High Viscosity and High Hardnes with zero pollution |
3. Main Applications of Zirconium Silicate Beads
Zirconium silicate beads are widely used for grinding and
dispersion of Color paste, electronic materials,
medicine, paint, coating ,titanium dioxide,calcium carbonate, gold
mine and copper mine etc.
4. Why zirconium silicate beads is suitable for Industrial mineral?
The processing cost of industrial mineral powder is relatively low
and in very limited profit,so the mineral
grinding gradually starts to use super-large equipment and
ultra-low-wear grinding media with higher
price/performance ratio to save the overall grinding cost.
5. Applicable Grinding Equipment& Beads Size
| Equipment | Generally Applicable Beads | Beads Size |
| Vertical Sand Mill | 95 Zirconia Beads 65 Zirconia Beads | 0.1-1.0mm |
| Horizontal Sand Mill | 65 Zirconia Beads Glass Beads | 0.6-1.0mm |
horizontal Sand Mill with rod pin. | 95 Zirconia Beads | 0.3-2.0mm |
Turbine Horizontal Sand Mill | 95 Zirconia Beads 65 Zirconia Beads | 0.3-2.0mm |
Special-shaped Cylinder Sand Mill | 95 Zirconia Beads 65 Zirconia Beads | 1.0-2.0mm |
Special-shaped dispersion disc Sand Mill | 95 Zirconia Beads 65 Zirconia Beads | 0.6-2.5mm |
| Ring Sand Mill | 95 Zirconia Beads | 0.4-1.5mm |
| Basket Grinder | 95 Zirconia Beads 65 Zirconia Beads | 1.0-3.0mm |
5. Why Choose Us?
Professional manufacturer,competitive price;
Equipped with the most advanced production line and testing
equipment in domestic;
Stricter quality control system,products can be traced and all the
products will be sampled testing before
deliveryeven in one small quantity.
Stable quality with more competitive price/performance ratio,
prompt delivery
