JZB40 JZB60 JZB120 JZB205 JZB400 Ceramic Blasting Media Zirconia
Sand for Metal Finish
1. Product Description of Ceramic Blasting Media
Ceramic Bead Blasting media is also called as ceramic blasting
meida,it selected the high quality zircon
sand as main material,then fused in electric furnace under high
temperature. Its unique crystal structure
determines its strong hardness and high impact resistance.
Ceramic bead blasting is one round solid beads,it has the
characteristics of smooth surface,good elasticity,
then it can be rebounded in multi-angles,especially suitable for
the surface finish of metal parts.
Ceramic Beads also has lower break-down rate,then it will provide
one clean and bright blasting condition,
also ensures
the worker to escape from the hidden danger of silicisos,also lower
the treatment cost of solid waste.
Ceramic blasting mediacan replace glass beads where one clean
working condition is required,also can
replace steel shot where one ferrous contamintaion is forbidden.
Now ceramic Beads is also one popular blasting media in various
blasting applications.
2. Main Applications of Ceramic Beads Blasting Media
| Main Technical Data of Ceramic Blasting Media |
| ZrO2 | SiO2 | Al2O3 |
| 60-66% | 25-30% | 7-13% |
| Vicker Hardness | True Specific Gravity | Bulk Density |
| ≥700 HV | ≥3.85 g/cm3 | 2.3g/cm3 |
| Particle Size |
| B20: 0.600-0.850mm | B30:0.425-0.600mm | B40:0.250-0.425mm |
| B60:0.150-0.300mm | B80:0.125-0.212mm | B100:0.106-0.180mm |
| B120:0.063-0.125mm | B150:0.000-0.125mm | B170:0.045-0.090mm |
| B205:0.000-0.063mm | B400:0.030-0.063mm | B505:0.010-0.030mm |
| Special specification can be customized |
3. Main Applications of Ceramic Bead Blasting Media
For light alloys such as aluminium alloy,magnesium alloy,titanium
alloy...
For metal parts such as aluminium parts,brass parts...
For stainless stell parts,high-carbon steels...
For plastics and rubber parts...
4. How to store ceramic beads?
Packing in a dry sealed barrel;
Store it in a dry and ventilated indoor warehouse;
Product shelf life is 3 years normally;
Use up ASAP once unsealed.
5. How to judge the quality of ceramic beads Blasting Media?
Good ceramic beads has rounder shape, easy to be judged in one high
magnified glass or even in naked eyes;
Good ceramic beads also has higher cleanliness no less than
99%,which will be sunk into the bottom of water
quickly. While the water in container is still cleaner,not muddy.
The quality also can be judged easily from the appearance of beads,
Good beads has whiter color and more
uniform particle size distribution.
Stable Supplier of Famous enterprises:
We are the stable supplier of Foxconn,Samsung electronics...
