Ceramic beads blasting media ZrO2 60% Min. B100 size 0.106-0.180mm
Description
Ceramic Bead also called zirconium silicate ceramic beads, zirconia
micro beads, ceramic blasting media etc., is produced by melting
process
at more than 2000℃ temperature , and then blow into micro beads
B20-B505, It's with smooth surface, strong toughness, not easily
broken, recyclable, and no dust pollution, is high quality sandblasting media for metal
parts.
Main used for:
- Sandblasting satin finish
- Sandblasting cleaning
- Deburring
- Descaling
- Pretreatment before spraying/coating
- Shot peening
Applicable for Dry sandblasting, wet sandblasting, vapour blasting
and microblasting, etc.
Specification
| Chemical Index | ZrO2 | SiO2 | Al2O3 |
| 60-65% | 25-30% | 7-13% |
| Typical Value | 62.20% | 26.10% | 9.05% |
| Bulk Density | 2.3g/cm3 |
| Specific Density | 3.85g/cm3 |
| Vickers Hardness | 700HV |
Particle Size Range
| B20: 0.600-0.850MM | B120: 0.063-0.125MM |
| B30: 0.425-0.600MM | B150: 0.053-0.106MM |
| B40: 0.250-0.425MM | B170: 0.045-0.090MM |
| B60: 0.150-0.300MM | B205: 0.000-0.063MM |
| B80: 0.125-0.212MM | B400: 0.030-0.063MM |
B100: 0.106-0.180MM | B505: 0.010-0.063MM |
Feature of Ceramic beads blasting meida
1. High hardness, long life and good elasticity
The ceramic beads has high hardness, vickers 700HV.It ensures that
the ceramic beads can
be shot peened for high-strength and ultra-high-strength structural
parts. The small deformation ensures that
the shape of the projectile does not change during impact.
2. Recyclable and improving efficiency
Ceramic bead blasting media has long service life and high cost
performance: The life of ceramic bead is more
than 20 times that of glass beads.
Ceramic beads not easy to be broken, and low wear, it can
effectively reduce the materials replacement times
and reduce the cost of workers to improve efficiency.
Application
Steel pipe, aluminum alloy pipe, titanium alloy pipe inner wall
sandblasting and rust cleaning
When cleaning the inner wall of the pipeline, a pressure-feeding
sand blasting machine and an air compressor
with sufficient capacity are required to connect the blasting hose
of the sand blasting machine with the inner wall
cleaner of the pipeline, and send it out by the blasting machine.
The high-speed air ceramic beads abrasive mixed
flow is sprayed onto the conical nozzle of the inner wall cleaner
of the pipeline, so that the ceramic sand abrasive is
guided to form a cone shape diffusion, thereby impacting the inner
wall of the pipeline to achieve the purpose of
cleaning the inner wall of the pipeline.
Other application for
- Sandblasting finishing
- Surface cleaning
- Surface Pretreatment
- Renovation of old work parts etc..
For all below materials surface treatment:
- Plastic
- Aluminum
- Copper
- Stainless steel
- Aluminum alloy
- Magnesium alloy
- Titanium alloy, etc.
Suitable sand blasting machine:
- Manual sand blasting machine,
- Automatic sand blasting machine,
- Open type series of sand blasting machine,
- Blasting room series.
