95 Yttrium Stabilized Zirconia Beads Grinding Media for high
hardness Materials
1. Product Description of 95 Zirconia Beads
95 Yttrium stabilized zirconia beads is one perfect grinding
media,it selects the high quality micron and sub-nano-level powder
as raw material,then made into different size by special
technology.
It contains about 95 ZrO2, also called as 95 zirconia beads, it has
the outstanding features of pearly smooth surface and high
strength,especially suitable for grinding and dispersion of high
viscosity materials.
2. Main Technical Data of 95 Zirconia Beads
| Commodity | Process | Physical Index |
95 Zirconia
Beads
Sintering Process | ZrO2 ≥95%
Y2O3 ≥4.5%
Others ≤0.5% | True Gravity≥6.0g/cm3
Bulk Density≥3.7g/cm3
Mohs Hardness :9 Mohs Vicker Hardness>1350HV Self Consumption<0.3 ppm/h
Compressive Strength≥2.0KN Φ2mm |
| size | Φ0.1-0.2mm,Φ0.2-0.3mm,Φ0.3-0.4mm,Φ0.4-0.6mm, |
| Φ0.6-0.8mm,Φ0.8-1.0mm,Φ1.0-1.2mm,Φ1.2-1.4mm, |
| Φ1.4-1.6mm,Φ1.6-1.8mm,Φ1.6-1.8mm,Φ2.0-2.2mm, |
| Φ2.2-2.4mm,Φ2.4-2.6mm,Φ2.6-2.8mm ,Φ4mm,Φ5mm, |
| Φ6mm,Φ7mm,Φ8mm,Φ9mm,Φ10mm,Φ12mm,Φ15mm |
| Φ17mm,Φ20mm,Φ25mm,Φ30mm,Φ40mm,Φ45mm,Φ50m... |
| Special products can be customized |
3. Main Features of 95 Zirconia Beads
Smooth surface, high hardness, good toughness;
Strong acid and alkali resistance, zero pollution to the treated
materials;
Strong compressive strength, good impact resistance, not easy to be
broken in high speed grinding process;
Good fluidity, low wear rate, little damage to the grinding
equipment.
4. Main Applications of 95 Zirconia Beads
Suitable for wear-resistant and corrosion-resistant industries,
such as coatings, textiles, pigments, painting
and dyeing...
Used for grinding and dispersing of high strength and high
toughness products, such as magnetic materials...
Used as grinding media where requires zero pollution in grinding
process, such as medicine, food, cosmetics...
Also used in ceramic industry,such as electronic ceramics,
refractory ceramics, structural ceramics etc.
5. Applicable Equipments
Bar pin horizontal grinder,
Turbine horizontal grinder,
Special-shaped dispersed disk grinder,
ring grinder, centrifugal grinder, basket grinder etc.
