Brand Name : | Zirnano |
Model Number : | 0.6-0.8mm~10mm |
Certification : | ISO9001, ISO14001 |
Price : | Negotiation |
Supply Ability : | 1500mt per year |
Delivery Time : | 5-20 days |
65 zirconium silicate grinding beads for ink, coating, painting and pestisides
Zirconium Silicate beads are sintered from zirconium silicate
powder and formulated with strict process controls, almost free of
bubbles and pores. With lower density, lower hardness and lower
crush load than Zirconia beads. It is adequate for the vertical
type mills in which heavy zirconia can not be used.
Zirconium Silicate beads grinding media are with the low price and high level of efficiency, available in different fractions ranging from 0.6 mm to 10 mm.
Manufacturing process: Sintering Method
ZrO2 | SiO2 | Other |
65% Min. | 30-35% | 1.0 % Max. |
Color | Bulk Density | True Specific Density | Vickers Hardness |
White | 2.5g/cm3 | 4.0g/cm3 | 900 HV |
Size Φ mm
0.6-0.8 | 0.8-1.0 | 1.0-1.2 | 1.2-1.4 | 1.4-1.6 | 1.6-1.8 |
1.8-2.0 | 2.0-2.2 | 2.5-3.0 | 3.0-3.5 | 4 | 5 |
6 | 7 | 8 | 10 | Special sizes can be customized. |
· Homogenous microstructure--Minimal fractured fragments
· High density and high hardness--Better milling efficiency
· High wear resistance--Longer working life
· High sphericity--Longer mill life
|
|
|
|
High speed mixing mill, Vibration mill, Grinder mill
